HV
Diagnostics
Distributor
FREE No Obligation Quote
Shop HV Diagnostics Products
VLF / DC Hipots
A very accurate true RMS measurement system measures and records load capacitance, insulation resistance (Megohmmeter), current, frequency, voltage, breakdown voltage and test duration. The HVA series of VLF instruments form the building blocks for the available Tan Delta and Partial Discharge instruments.
Tan Delta Cable Diagnostics
The Tan Delta (TD) series of diagnostic test instruments was developed to help cable engineers evaluate the condition of their MV and HV cables. Tan Delta (TD), or Dissipation Factor, is an excellent diagnostic tool to evaluate both aged and new cables systems, particularly when evidence of moisture ingress into the cable is concerned.
Partial Discharge Detection
What was once thought to be unachievable a mere twenty years ago, on-site Partial Discharge (PD) diagnostics in the field has developed significantly over the past decade. Partial Discharge detection used to be consigned to special test bays in factory and laboratory environments.
Dieletric Oil Testing
Electrical insulation oils form the critical insulation medium for many of today’s electrical apparatus, such as transformers, tap-changers, circuit breakers, cables, bucket trucks etc. When this critical insulation system becomes contaminated or degraded over time, the dielectric properties can be adversely affected causing a potential breakdown or flashover, often resulting in catastrophic consequences.
Cable ID & Phasing
Ever since electrical cables have been used to distribute electricity, electrical utilities have been faced with the potentially dangerous task of having to safely identify (ID) a cable, either at its ends or somewhere along its length. The EZ-Cable ID® allows electrical testing personnel to accurately and effectively identify either one, two or three cables or cores anywhere along the length of the cable in one identification process.
Fault Location Devices
Cable faults can occur in a variety of ways during the lifecycle of cable. They can occur when new, during commissioning of the cables or initial energization, or many years after the cables have been put into service. The types of faults can also vary considerably, from dead shorts (also sometimes called “bolted faults”) to a cable that has catastrophically faulted and completely blown open.
Certified HV Diagnostics Distributors Since 1984
Butler & Land
HV Diagnostics Inc. based in Atlanta, GA, USA provides the electrical industry with field proven, sophisticated and reliable electrical test equipment including High Voltage DC & VLF (Very Low Frequency), Fully Automatic Oil Testers, Cable Testing and Diagnostic Systems, Relay Testing and Current Injection systems etc.
In addition to being a leading supplier and manufacturer of electrical test equipment, we also offer excellent technical support and provide specialized electrical testing services that include cable testing, cable fault location and cable diagnostics. Our equipment is capable of testing motors, generators, switchgear, transformers, relays and cables.
HV Diagnostics Inc. based in Atlanta, GA, USA provides the electrical industry with field proven, sophisticated and reliable electrical test equipment including High Voltage DC & VLF (Very Low Frequency), Fully Automatic Oil Testers, Cable Testing and Diagnostic Systems, Relay Testing and Current Injection systems etc.
If you don’t see the item you are looking for, or we are currently out of stock, please contact our Sales Department for current price and delivery at 800-527-6870 or sales@butlerandland.com
